FlySky FS-i6 2.4G 6CH PPM RC Transmitter With FS-iA6B Receiver

4,499.00

  • Transmitter: FS-i6X (6 Channels)
  • Receiver: FS-iA10B (10 Channels)
  • RF Range: 2.408-2.475 GHz
  • RF Power : < 20 dBm
  • RF Channel: 135
  • Bandwidth: 500 kHz
  • Total Weight: 392 gm
  • Power: 6V DC 1.5A
In Stock
Category:

Description

When using a drone, a transmitter is one of the most important components. You can’t fly a multirotor without it because it uses radio signals to send commands wirelessly to a Radio Receiver, which is connected to an aircraft or multirotor that is being remotely controlled.

This is the FlySky FS-i6 2.4G 6CH PPM RC Transmitter With FS-iA6B Receiver. It is a great entry-level radio for those just starting in the field of drones flying.

Above all, you get a slim, modern radio transmitter that fits nicely in your hands and weighs just under 400 gm. It won’t test your arm stamina on those long flights. This radio is also really practical with a 3-position switch. It has two adjustable knobs for flight modes/ multiple flap positions.

You will get the new FS-iA6B receiver with this kit. This is a compact 6-channel receiver with a range exceeding 500m in addition. it comes with a dual antenna for excellent reception and interference rejection capabilities.

Each transmitter has a unique ID and so when binding; the receiver remembers this ID and accepts data from that transmitter only. This avoids picking up other transmitter signals and dramatically decreases inference and increases safety.

Features:

  1. 10 channel 2.4GHz radio with telemetry capability
  2. Automatic Frequency Hopping Digital System (AFHDS) spread spectrum technology
  3. Transmitters come pre-bound to the receiver
  4. Multiple control switches including a 3-pos switch and two potentiometers
  5. Easy to use and program
  6. 20 model memory
  7. Trainer port
  8. Backlit LCD screen displays real-time transmitter and receiver voltage

Specifications :

Specification  for FS-i6X RC Transmitter :
  1. Item: FS-i6X RC Transmitter
  2. Tx Channel: 6
  3. Model Type: Fixed-Wing/Glider/Helicopter
  4. RF Range: 2.408-2.475GHz
  5. RF Power : < 20dBm
  6. RF Channel: 135
  7. Bandwidth : 500KHz
  8. 2.4GHz System : AFHDS 2A / AFDHS
  9. Modulation Type: GFSK
  10. Stick Resolution: 4096
  11. Low Voltage Warning: < 4.2V
  12. DSC port: PS/2 Port PPM
  13. Chargeable: No
  14. Antenna Length: 26mm (Dual Antenna)
  15. Weight: 392g
  16. Power : 6V DC 1.5A
  17. Display: STN Transflective Display, LCD 128×64 Lattice, VA 73x39mm, LCD with white backlight
  18. Size : 174 x 89 x 190 mm
  19. Online Update: Yes
  20. Color: Black
  21. Certificate: CE0678, FCC
Specifications for FS-iA10B RC Receiver:
  1. Rx Channels: 10
  2. Suitable models: Airplane / glider / helicopter Health
  3. Frequency range :2.4-2 .48 GHz
  4. Transmitting power: not more than 20dBm
  5. Receiver sensitivity:-105dBm
  6. 2.4G modes: automatic frequency second generation digital system
  7. Encoding: GFSK
  8. Antenna length: 26 mm * 2 (dual antenna)
  9. Weight: 19.3 g
  10. Input power :4.0-6 .5 V DC
  11. Dimensions: 47 x 33.1 x 14.7 mm
  12. Color: Black
  13. Certification: CE0678, FCC
  14. i-BUS Interface: Yes
  15. Data acquisition interface: Yes
  16. Color: Black.
  17. Model Type : Airplane / Glider / Helicopter
  18. Compatible Transmitter: Compatible with FS-i4, FS-i6, FS-i10, FS-GT2E, FS-GT2G

Package Includes :

1 x  Fly sky FS-i6X 6CH 2.4GHz AFHDS 2A RC Transmitter.
1 x FS-iA10B 2.4GHz 10CH Receiver with Binding cable.
1 x PS2 to USB Update Cable.
1 x User Manual.
